Step-by-Step Guide to Maintaining Your Split System Air Conditioner
Disassembling the Pipe Clamp Board
Step 1: Disassemble the Pipe Clamp Board
Locate the pipe clamp board on the evaporator unit. It is typically secured by screws. Using a screwdriver, carefully remove the screws and separate the pipe clamp board from the evaporator.
Removing the Screw on the Evaporator
Step 2: Remove the Screw on the Evaporator
Identify screw 1 on the evaporator located at the left fixed plate. This screw secures the evaporator to the frame. Using a screwdriver, carefully remove screw 1.
